Palmdoc 2

Technical specification

  • Model name: Palmdoc II
  • Display: LCD
  • External Output: USB Data Port
  • Auto electrode inserting detection
  • Auto sample loading detection
  • Auto reaction time cut-down
  • Auto insufficient blood detection
  • Temperature warning
  • Measurement Units: Preset by factory only
  • Measurement Range: 1.1 – 33.3 mmol/L
  • Operating Condition: 50°F – 104 °F (10°C – 40°C)
    10-85% R.H. (non-condensing)
  • Storage/Transportation Condition: 39.2°F – 104°F (4°C – 40°C), 10-85% R.H.
  • Memory: 900 test results with date and time
  • Power supply: Two (2) 1.5 Volt AAA Alkaline Batteries
  • Battery life: Over 500 tests
  • Meter dimensions: 3.8 in. (L) x 2.13 in. (W) x 0.86 in.(H)
    96.4 mm (L) x 54 mm (W) x 22.06 mm (H)
  • Meter weight: 2.78 oz with batteries, 79g
  • Verified by TUV to adhere to ISO:15197:2015

The specifications may be changed without prior notice.
